เปิดใช้ MACsec สำหรับฟีเจอร์อีเทอร์เน็ต

# MACSEC HAL

# This is a mock MACsec HAL implementation with keys embedded in it. Replace with vendor specific HAL
PRODUCT_PACKAGES += android.hardware.automotive.macsec-service

# wpa_supplicant build with MACsec support

PRODUCT_PACKAGES += wpa_supplicant_macsec

# configuration file for wpa_supplicant with MACsec

PRODUCT_COPY_FILES += \
    $(LOCAL_PATH)/wpa_supplicant_macsec.conf:$(TARGET_COPY_OUT_VENDOR)/etc/wpa_supplicant_macsec.conf \
    $(LOCAL_PATH)/wpa_supplicant_macsec.rc:$(TARGET_COPY_OUT_VENDOR)/etc/init/wpa_supplicant_macsec.rc

# wpa_supplicant_macsec.conf
eapol_version=3
ap_scan=0
fast_reauth=1
# Example configuration for MACsec with preshared key
# mka_cak is not actual key but index for MACsec HAL to specify which key to use
# and make_cak must be either 16 digits or 32 digits depends the actually CAK key length.
network={
        key_mgmt=NONE
        eapol_flags=0
        macsec_policy=1
        macsec_replay_protect=1
        macsec_replay_window=0
        mka_cak=00000000000000000000000000000001
        mka_ckn=31323334
        mka_priority=128
}

# wpa_supplicant_macsec.rc
service wpa_supplicant_macsec /vendor/bin/hw/wpa_supplicant_macsec \
        -dd -i eth0 -Dmacsec_linux -c /vendor/etc/wpa_supplicant_macsec.conf
        oneshot

# init.target.rc
on late-fs
    …
    wait /sys/class/net/eth0
    start wpa_supplicant_macsec
    …

# Example of com.google.android.connectivity.resources overlay config
<?xml version="1.0" encoding="utf-8"?>
<!-- Resources to configure the connectivity module based on each OEM's preference. -->
<resources xmlns:xliff="urn:oasis:names:tc:xliff:document:1.2">
    <!-- Whether the internal vehicle network should remain active even when no
         apps requested it. -->
    <bool name="config_vehicleInternalNetworkAlwaysRequested">true</bool>
    <string-array translatable="false" name="config_ethernet_interfaces">
        <!-- Not metered, trusted, not vpn, vehicle, not vcn managed, restricted -->
        <item>macsec0;11,14,15,27,28;ip=10.10.10.2/24 gateway=10.10.10.1 dns=4.4.4.4,8.8.8.8</item>
    </string-array>
    <string translatable="false" name="config_ethernet_iface_regex">macsec\\d</string>
</resources>

/**
 * MACSEC pre-shared key plugin for wpa_applicant
 *
 * The goal of this service is to provide function for using the MACSEC CAK
 *
 */
@VintfStability
interface IMacsecPSKPlugin {
    /**
     * For xTS test only, not called in production
     *
     * @param keyId is key id to add
     * @param CAK, CAK key to set
     * @param CKN, CKN to set
     *
     * @return ICV.
     */
    void addTestKey(in byte[] keyId, in byte[] CAK, in byte[] CKN);


    /**
     * Use ICV key do AES CMAC same as ieee802_1x_icv_aes_cmac in wpa_supplicant
     *
     * @param keyId is key id to be used for AES CMAC
     * @param data
     *
     * @return ICV.
     */
    byte[] calcICV(in byte[] keyId, in byte[] data);


    /**
     * KDF with CAK key to generate SAK key same as ieee802_1x_sak_aes_cmac in wpa_supplicant
     *
     * @param keyId is key id to be used for KDF
     * @param seed is key seed (random number)
     * @param sakLength generated SAK length (16 or 32)
     *
     * @return SAK key.
     */
    byte[] generateSAK(in byte[] keyId, in byte[] data, in int sakLength);


    /**
     * Encrypt using KEK key, this is same as aes_wrap with kek.key in wpa_supplicant
     * which used to wrap a SAK key
     *
     * @param keyId is key id to be used for encryption
     * @param sak is SAK key (16 or 32 bytes) to be wrapped.
     *
     * @return wrapped data using KEK key.
     */
    byte[] wrapSAK(in byte[] keyId, in byte[] sak);


    /**
     * Decrypt using KEK key, this is same as aes_unwrap with kek.key in wpa_supplicant
     * which used to unwrap a SAK key
     *
     * @param keyId is key id to be used for decryption
     * @param sak is wrapped SAK key.
     *
     * @return unwrapped data using KEK key.
     */
    byte[] unwrapSAK(in byte[] keyId, in byte[] sak);
}

$ atest VtsHalMacsecPskPluginV1Test

# ping -I macsec0 10.10.10.1
